Adaptors for reversing cameras

There may be occasions where you need to connect two female RCA Phono connectors together.  This gender changer allows you to do so.

ACC093 - BNC Plug to RCA Phono (Female)

Some Sat Navs and Dashcams have a small socket that looks similar to a headphone jack.  This is designed to accept video (and sometimes audio).  This adaptor cable allows you to attach a video feed using the yellow RCA/Phono plug (audio too if your camera is equipped with a microphone).  If you are adapting one of our 4 pin cameras then you will need a 4 Pin to RCA/Phono adaptor and some of our phono couplers to allow everything to mate together.

Please note that sometimes you will see the same type of connector on cameras, most commonly cameras which attach with a bolt (as this connector allows the cable to fit through the small cable hole for the bolt).  This adaptor WILL NOT work on the camera - as this isn't designed to give power to a camera.  We do not have adaptors for the cameras since we have seen the power enter on different poles.

We had these made up so that they would plug in to the 2.1mm DC sockets that are on most of our monitor wiring harnesses.  Fuse taps are a convenient way to tap into a power supply for your new camera system.

We had these made up so that they would plug in to the 2.1mm DC sockets that are on most of our monitor wiring harnesses.  Fuse taps are a convenient way to tap into a power supply for your new camera system.

A 12V lighter plug connection is still a popular option for people who either wish to test their reversing camera kit before hardwiring in, or for people who want the ultimate easy install.

We had these made up so that they would plug in to the 2.1mm DC sockets that are on most of our monitor wiring harnesses.  Fuse taps are a convenient way to tap into a power supply for your new camera system.

99% of the time, if you see a DC socket on a reversing camera or monitor, it will be a 2.1mm/5.5mm connector.  This wire allows you to provide power to this type of socket, and has an inline 3 amp fuse on the red input wire. Total length of this power adaptor is 150CM.

This is a 3 amp fused 2.1mm/5.5mm DC socket with 100cm red (+12/24V) and black (earth) wire attached. This is used in instances where you have bare red/black wires that you wish to connect one of our extensive range of adaptors with DC plugs to.

We have instances of people using a 24V vehicle with a Phono RCA based cameras and cables. In these circumstances, you would require a dropper for the camera supply to regulate the output for the camera down to 12V. We also sell these to people that want to protect their phono cameras from any voltage fluctuations on 12V systems. These are only suitable for powering a camera and not a complete system (all of our premium systems have voltage regulators built-in already).

The piggyback fuse holders have become a popular method of providing power to the reversing camera system due to their ease and simplicity. We provide a 3 amp fuse that fits in the top slot which is the correct rating for all of our reversing camera kits, the lower slot will accept the original fuse to whatever circuit you are tapping off. You then attach the red wire to the power supply of the monitor either with the crimp, or by cutting that off and soldering (our preferred method).

The piggyback fuse holders have become a popular method of providing power to the reversing camera system due to their ease and simplicity. We provide a 3 amp fuse that fits in the top slot which is the correct rating for all of our reversing camera kits, the lower slot will accept the original fuse to whatever circuit you are tapping off. You then attach the red wire to the power supply of the monitor either with the crimp, or by cutting that off and soldering (our preferred method).

Sometimes you wish to split one power supply cable so that it powers two separate devices eg a monitor and an MDVR, or two phono/RCA based reversing cameras. This cable allows you to do so.

Sometimes you wish to split one power supply cable so that it powers four separate devices eg four phono/RCA based reversing cameras. This cable allows you to do so.
