Swift / Autotrail / Bessacarr / Sargent Electrical compatible reversing camera adaptors

If you need to replace a faulty RV77 / CC-47 Reversing Camera, originally fitted to some Swift, Autotrail, or Bessacarr Motorhomes, then this is one of the bundles we have supplied customers with for many years. It is worth mentioning that our reversing camera has slightly different dimensions from the original camera. In this bundle, we will supply an adaptor cable to go from our 4-pin screw connector to the 6-pin PS2 connector that is fitted to the original cable. Our adaptor has been wired up the same way as the original was. The adaptor cable has a trigger wire added; if the original camera had an orange trigger lead connected at the back (to reverse feed), then you will need to connect our trigger wire to this (if not, insulate this wire).

If you need to replace a faulty RV77 / CC-47 Reversing Camera, originally fitted to some Swift, Autotrail, or Bessacarr Motorhomes, then this is one of the bundles we have supplied customers with for many years. It is worth mentioning that our reversing camera has slightly different dimensions from the original camera. In this bundle, we will supply an adaptor cable to go from our 4-pin screw connector to the 6-pin PS2 connector that is fitted to the original cable. Our adaptor has been wired up the same way as the original was. The adaptor cable has a trigger wire added; if the original camera had an orange trigger lead connected at the back (to reverse feed), then you will need to connect our trigger wire to this (if not, insulate this wire).

The RV-207 reverse camera is often seen on Swift, Autotrail, and Bessacarr motorhomes.  It is a twin camera system that runs to a Sargent Electrical EM5 series control box.  This bundle is for a compatible driving+reversing camera, plus the adaptor leads to convert it to the 6 pin connector required.  The cameras are fitted with a high spec 1/3" Sony CCD image sensor, one has an 8mm lens to give 45 degrees (the best angle for rear view/always on driving), the other has a wide angle lens for parking.  As our camera uses a 4 pin connector, this bundle includes discounted adaptors, which converts our 4 pin connectors to the same 6 pin connectors required on the original cabling.  We have sold many hundreds of these bundles over the years with total success.

The RV-207 reverse camera is often seen on Swift, Autotrail, and Bessacarr motorhomes.  It is a twin camera system that runs to a Sargent Electrical EM5 series control box.  This bundle is for a compatible driving camera, plus an adaptor lead to convert it to the 6 pin connector required.  The camera is fitted with a high spec 1/3" Sony CCD image sensor, and an 8mm lens to give 45 degrees (the best angle for rear view/always on driving).  As our camera uses a 4 pin connector, this bundle includes a discounted adaptor, which converts our 4 pin connector to the same 6 pin connector required on the original cabling.  We have sold many hundreds of these bundles over the years with total success.

The RV-207 reverse camera is often seen on Swift, Autotrail, and Bessacarr motorhomes.  It is a twin camera system that runs to a Sargent Electrical EM5 series control box.  This bundle is for a compatible driving camera, plus an adaptor lead to convert it to the 6 pin connector required.  The camera is fitted with a high spec 1/3" Sony CCD image sensor, and a wide angle lens to give 120 degrees.  As our camera uses a 4 pin connector, this bundle includes a discounted adaptor, which converts our 4 pin connector to the same 6 pin connector required on the original cabling.  We have sold many hundreds of these bundles over the years with total success.

An adaptor bundle set, designed to replace the mirror monitor on Sargent Electrical reversing camera systems that use the EM5 series boxes.  Commonly seen on Swift, Autotrail, Bessacarr motorhomes.  Our mirror monitor uses a slimline 8 pin plug, which then fits to our Adaptor I (converts to a PS/2 connector, which we have had pinned out to match Sargent's cabling).

For a number of years we have stocked these adaptors to support customers who have a 6 pin mini din (PS/2) cable in their vehicle.

We have used this adaptor cable to support Swift and Autotrail Motorhome Owners when replacing their original failed factory-installed reversing camera. The adaptor is designed so that one of our 4 pin reversing cameras can be used in the replacement, simply adding this adaptor on to our camera so that it fits the original 6 pin socket on the main extension cable back to the original camera.

As part of our extensive range of motorhome reversing camera system support adaptors, this one allows people who have a RVM720/730 Mirror Monitor to change the monitor display to either a stereo headunit or a dash monitor with phono RCA inputs.

We received an email from a lovely chap called Tom who had an issue with his twin lens driving / reversing camera fitted as standard on his Bessacarr motorhome.  We have for a long time stocked adaptors to support customers such as Tom in this predicament.  Tom very kindly has sent in a couple of photos allowing us to use them on our site so that they may help other customers in a similar position to him.

The Swift / Autotrail / Bessacarr/ Sargent Electrical reversing camera cable adaptors are suitable for Sargant Electrical Twin Lens systems using the boxes EM5.0 / EM5.6.  We hold two adaptors, one with a fly lead (for the camera looking down at the floor.  One without a fly lead (for the driving camera looking down the road) - if you are only replacing one lens then it is important to order the correct adaptor for it to work.

You may also find the same system installed on various Swift and Autotrail motorhomes.
